Working Title team's modes for the G1000 and CJ4.

This is the home of mods for the new Microsoft Flight Simulator from the Working Title team. We have a number of projects either in the works or planned. Here is the status of what is currently being worked on and links to downloadable releases.
ProjectDescriptionCurrent VersionDocumentation
CJ4Perfomance and avionics improvements for the Citation CJ4in development
G1000Fixes and enhancements for the stock G1000 avionics packagev0.2.0docs
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages

CJ4 - Upgrade 2.0

A major CJ4 upgrade.

https://github.com/Working-Title-MSFS-Mods/fspackages

Key Features


  • Fixed Direct To routing when attempting to go direct to IAF or enroute waypoints
  • Enabled proper EXEC/CANCEL MOD function and removed the 'Activate' logic
  • Created Custom Font and implemented across FMC, PFD and FMS
  • Updated FMC Layout, Coloring, Keyboard Lighting; added message line and EXEC notification to FMC layout
  • Fixed LEGS page listing to include all flight plan and approach waypoints
  • Added PERF pages and functions, including takeoff, landing and fuel management
  • Added IDX pages and functions, including progress pages, approach details
  • Fixed PFD and MFD NAV BAR details
  • Adjusted engine performance and fuel flow to more closely reflect reality (much more work to be done)
  • Removed reverse thrust
  • Eliminated erroneous cabin pressure alarms (will need to be remodeled later)
Direct To Page


  • Adjusted waypoint listing to show origin, departure, enroute, arrival and first approach fix
  • Added proper handling for activating a direct to the IAF in an approach without causing the plane to fly back to a prior fix and auto activating the approach from present position.
  • Added EXEC/CANCEL MOD logic to replace 'Activate' logic
LEGS Page


  • Fixed errors in display of flight plan waypoints
  • Added approach waypoints to legs listing
IDX / INIT REF Index Page


  • Status Page - shows database, time, date
  • GNSS Pos Page - shows current GPS Lat/Lon, date, time
  • PROG Page 1 - shows last, current, next and destination waypoints, distance in flight plan from current location and ETE
  • PROG Page 2 - shows current wind, headwind component, tailwind component, ISA DEV, flight plan cross track deviation and TAS
  • Database Initial Page now allows selecting waypoint from database
  • Database Airport Page now displays base data for any selected airport
  • Arrival Data Page now displays the selected approach airport, runway, runway elevation, approach type, approach name, frequency and approach course.
PERF / PERF INIT


  • Added Main Menu
  • Added Perf Init Page to set/read weight, fuel and cruise altitude
  • Added Takeoff Ref page 1 with working calculator for takeoff data for the selected departure runway, including wind, pressure altitude, runway condition, runway length
  • Added Takeoff Ref page 2 with calculated V speeds and calculated takeoff distance, including selectors for Flaps and Anti Ice state. Vspeeds can be sent to PFD and appear in magenta color when set by FMC.
  • Added Fuel Management page 1 calculating fuel remaining, displaying fuel flow, allowing setting of reserve fuel, showing endurance, range and endurance to reserve fuel and specific range.
  • Added Fuel Management page 2 showing fuel flow in each engine and fuel burned, with added 'reset initial fuel' button
  • Added Approach Ref page 1 with destination details, runway details and landing performance calculator, including headwind/crosswind components, runway condition, pressure altitude and temperature variables.
  • Added Approach Ref page 2 with calculated Vref and Vapp speeds and calculated landing field requirements and landing field available length. Vspeeds can be sent to PFD and appear in magenta color when set by FMC.
TUN Page


  • Updated layout and fields
FPLN Page


  • Updated layout and fields
  • Enabled first waypoint line management on page 1
  • Added EXEC/CANCEL MOD logic to replace 'Activate' logic
DEP/ARR Page


  • Added EXEC/CANCEL MOD logic to replace 'Activate' logic
DSPL MENU Page


  • Updated layout and established template (to do)
MFD ADV Page


  • Updated layout and established template (to do)
PFD


  • Removed erroneous display of GS/TAS from PFD Map
  • Fixed NAV BAR at bottom of PDF to display current accurate COM1 COM2 ATC1 RAT and UTC
  • Set AoA to only appear with Flaps 35
  • Added VRef(VRF) and Vapp(VAP) to the speed tape
  • Setup PFD coloring so that VSpeeds set by FMC are magenta and when manually set or edited they are set to cyan
  • Updated fonts to custom font
MFD


  • Removed erroneous display of GS/TAS from MFD Map
  • Fixed NAV BAR at bottom of MFD to display current accurate GS TAS RAT SAT and ISA DEV
  • Updated fonts to custom font
  • Removed bad CAS messages for PITOT and INERT SEP (more to do here...)
Misc


  • Added YD functionality (credit: musurca)
  • Added/fixed many gear-related warnings (credit: musurca)
  • Improved exterior lighting (Landing/taxi light visibility) (credit: Uwajimaya)
Known Issues


  • You cannot currently select Direct-To of a fix on your approach that is not the initial approach fix. This is a limitation of the sim flightplan system at present. We are investigating solutions to this issue.
  • After using Direct-To, the navigation will not always automatically sequence to the next fix and may enter ROL mode. You can re-activate NAV to navigate to the next fix if you encounter this issue.
  • There are cosmetic issues regarding the PFD and MFD (shapes, text, alignments). The PFD and MFD have not gotten a full layout overhaul as of this time.
  • The aircraft is still using the built-in MSFS autopilot (for now). All the existing limitations of that still apply. It does behave a bit better with the engine performance changes.
Click to expand...

CJ4 = upgrade v0.3.0

A new CJ4 upgrade.

https://github.com/Working-Title-MSFS-Mods/fspackages


Upgrade video.




Key Features


  • Complete rebuild of templating system to accommodate FMS3000 specific formatting 'quirks' including inconsistent page numbering, inconsistent indenting, proper color formatting, etc
  • Enhanced EXEC, ACT/MOD and Message handling and resolved several EXEC related bugs
  • Added AoA ON/OFF/AUTO PFD Menu Line and adjusted AoA Show/Hide logic
  • Updated LEGS page Layout
  • Built new FPLN pages
  • Further enhanced PERF pages, added temporary landing weight calculation (to be further refined with actual performance prediction)
  • Added additional IDX pages, including DATABASE pages allowing lookup of any navaid in the database
  • Improved autopilot handling with special attention to FLC mode (works much better for managing climb and descent speed, but still is flaky if enabled shortly after takeoff)
  • Added functionality to several in-cockpit knobs and switches
  • Added aircon/fan sounds as well as seatbelt announcement
  • Improved cockpit lighting
  • Added externally visible cabin lighting
  • Added DSPL MENU & MFD ADV pages and functionality, including the ability to turn on/off supported map features and step through flight plan waypoints on PLAN view
  • Improved TUN page handling of frequencies, including parsing 8.33/25khz spacing properly
Direct To Page


  • Improved formatting
LEGS Page


  • Improved formatting
IDX / INIT REF Index Page


  • Updated all templates, indents, titles and fonts throughout the pages and menus
  • PROG Page 1 - updated PROG page to protect against errors
  • PROG Page 2 - shows current wind, headwind component, tailwind component, ISA DEV, flight plan cross track deviation and TAS
  • Database Pages now work for all waypoint types (Airport, VOR, NDB, RNAV Waypoints)
PERF / PERF INIT


  • Updated all templates, indents, titles and fonts throughout the pages and menus
  • Updated takeoff and landing calculations
  • Added further error protection on all PERF pages
  • Updated landing weight to a calculated field (to be enhanced further)
  • Takeoff and landing weights will turn yellow when they have exceeded the maximum values
  • Fuel used page updated with reset button working
TUN Page


  • Updated layout and fields
  • Added shorthand inputs and all valid frequencies should be enterable
FPLN Page


  • Updated all templates, indents, titles and fonts throughout the pages and menus
  • Improved EXEC, ACT/MOD and Message logic
DEP/ARR Page


  • Updated all templates, indents, titles
DSPL MENU Page


  • DSPL MENU on FMC now allows you to toggle intersections, navaids, airports, and flight plan altitude restrictions onto the PFD and MFD displays
MFD ADV Page


  • MFD ADV on FMC now allows you to cycle through flight plan waypoints on the MFD PLAN page
PFD


  • Updated NAV BAR at bottom of PFD to display UTC with HH:MM:SS
  • Adjusted PFD menu to remove inaccurate 'units' submenu and add AOA menu item allowing AoA to be on AUTO, ON or OFF. Auto keeps Flaps 35 logic, ON turns AoA on for all phases of flight and OFF removes the AoA for all phases of flight.
  • Enabled viewing of intersections, navaids, airports, and flight plan altitude restrictions on the MFD and PFD
MFD


  • Enabled stepping through waypoints in PLAN mode via MFD ADV page on FMS
  • Enabled viewing of intersections, navaids, airports, and flight plan altitude restrictions on the MFD and PFD
Misc


  • Improved Autopilot handling, specifically for FLC mode (credit: wizzlebippi)
  • Pilot fan knob works with accompanying sound (credit: J-Hoskin)
  • CLIMATE CONTROL knob works (credit: J-Hoskin)
  • COCKPIT TEMP knob works (credit: J-Hoskin)
  • SOURCE knob works (credit: J-Hoskin)
  • Seatbelt button works with accompanying sound (credit: J-Hoskin)
  • Improved cockpit and cabin lighting (including externally visible cabin lights at night)
Known Issues

*FLIGHT PLAN BUG: Entering in waypoints on the flight plan route page does not correctly update the page. (6:38 on demo video).

  • You cannot currently select Direct-To of a fix on your approach that is not the initial approach fix. This is a limitation of the sim flightplan system at present. We are investigating solutions to this issue.
  • After using Direct-To, the navigation will not always automatically sequence to the next fix and may enter ROL mode. You can re-activate NAV to navigate to the next fix if you encounter this issue.
  • There are cosmetic issues regarding the PFD and MFD (shapes, text, alignments). The PFD and MFD have not gotten a full layout overhaul as of this time.
  • The aircraft is still using the built-in MSFS autopilot (for now). All the existing limitations of that still apply. It does behave a bit better with the various enhancements applied.
  • TUN page doesn't update automatically when radios are updated externally - reopening the TUN page will reflect these changes.
  • Performance pages don't currently have input error handling for wind, temp or QNH. These values must be entered correctly and completly in the proper format for the page to work. Note that valid wind directions are 001 through 360 as of now.
Click to expand...

G1000 v0.3.0 upgrade

With the release of the MSFS 1.9.3.0 patch today, you can expect most if not all mods to require updates to work correctly. The Working Title team advises you to remove all mods, including our CJ4 and G1000 mods, from your Community folder until such time as they are updated.
Click to expand...


https://github.com/Working-Title-MSFS-Mods/fspackages
Main features


  • Added track-up mode for both PFD and MFD
  • Fixed unwanted U-turn on ACTIVATE APPROACH
  • Fixed reversed behavior of NOSE UP/DN buttons in FLC mode
  • Added a preference saving system tied to plane model
  • Configured it to currently preserve the following across sessions:
    • PFD and MFD brightness
    • V Speeds
    • Track up mode
    • Barometer mode
    • HSI settings for BRG1, BRG2, and DME
  • Support loading plane configuration information even in encrypted planes
  • Detect hardware avionics knobs in all models and configure them automatically
  • Added support for additional XML-configurable ENGINE pages on MFD
  • Lots of changes to colors and styling to closer match reality
PFD and MFD enhancements


  • Added a flight path marker on the PFD when in Syn Vis mode above 30kts
  • Added new vertical column type gauge for engine display
  • Updated circular gauge to support custom gradations and rounding
  • Added a new blinking yellow status for engine gauges
  • Correctly handle wind data when on ground or wind speed <1 knot
  • Fixed reversed wind arrow at all times on MFD
  • Improve MFD soft key menus, including new switch for TRACK UP
  • Increased MFD max range to 2000 with more intermediate steps
  • Move weather radar to MAP page group, only show if radar is on board
  • Change brightness of PFD/MFD knobs and softkeys along with display
Styling improvements


  • Change PFD and MFD headers to more closely match the real font size, spacing, and colour
  • More accurate colors on attitude indicator, horizon, and map; new gradient on horizon
  • Updated flight director and attitude arrows
  • Updated styling of airport waypoint info page (more to come)
  • Updated styling of softkey menus to be more realistic
Miscellaneous


  • Added sample engine page configuration for G36 Bonanza
  • Fix false DON'T SINK alert when flying patterns / touch and goes
  • Improve representation of whole numbers as decimals
Click to expand...


CJ4 v0.3.1 upgrade

This update focuses on compatibility with MSFS 1.9.3, but also includes a few new features and quality of life updates as well.


https://github.com/Working-Title-MSFS-Mods/fspackages


Key Features


  • Now compatible with MSFS 1.9.3
FPLN Page


  • Incorrect page numbering has been fixed
  • Added colors to selected SIDS/Runways for DEP page only (WIP due to 1.9.3 patch)
  • Added ability to insert waypoints in the middle of the flight plan
  • Fixed issue where FPLN would always return to page 1 after EXEC
DEP/ARR Page


  • Executing a change doesn’t move you away from the page
  • Improved formatting
LEGS Page


  • Adjusted layout and colors to better match the real unit
TUNE Page


  • Fixed issue where nav radios would not update the sim radios on update
PFD/MFD


  • Adjusted font size, color, and spacing for better readability and accuracy (still a WIP)
PFD


  • Added DME readout for VORs
  • Changed to use correct colors (Magenta for FMS, green for ground NAVAIDS)
  • Changed formatting of VOR info block to match the correct layout and element spacing
Aircraft Exterior Model


  • Aircraft lights have been updated in style to add some lens flaring, brighter visibility, and textures (thanks @Uwajimaya)
Click to expand...

CJ4 v0.4.0 upgrade

CJ4 upgrade.

https://github.com/Working-Title-MSFS-Mods/fspackages


Video:


Key Features


  • New custom engine fuel consumption model code based on FJ44 curves and pilot input
  • Overhauled LEGS page for more flexibility and real unit functions (WIP)
  • Many FPLN page bug fixes
  • A few quality of life and critical bug fixes
  • Overhaul of DEP/ARR pages and working STAR approaches (thanks @tscharlii)
  • Added functional options in the UPR MENU
Engine Model


  • Engine fuel consumption model has been custom coded and replaces the sim fuel consumption. Fuel consumption, especially at cruise, should be much, much closer to published. Expect 1800-1850pph per side at ISA full power at sea level and 500-800pph per side at cruise, depending on altitude, mach, and power settings.
  • Thrust now scales exponentially with N1 instead of linearly. Power settings should feel much more accurate.
Flight Model


  • Added gear drag (Was non-existent before)
  • Greatly reduced spoiler drag & pitch down moment (You shouldn't be losing airspeed in a 30 degree nose down dive with the speedbrakes out)
  • Reduced flap drag
LEGS Page


  • Added ability to insert a new fix
  • Added ability to remove whole segments by pressing LSK of one fix and then LSK of another
  • Added ability to to direct-to a leg by pressing LSK of the fix and then dropping onto the magenta line
  • Added ability to delete individual fixes
  • Magenta fix distance updates distance to go as aircraft moves
  • Fixed issue where unable to delete with a departure active
  • Made the WORKING prompt more consistent
  • Added feature to show runway where possible
  • Disabled the ability to adjust approach fixes due to simulator limitations
  • Each waypoint now shows the distance to the next fix instead of the cumulative flight plan distance.
  • Blue waypoint is the FROM waypoint
  • Magenta waypoint is the current TO waypoint
  • Only fixes with an altitude or speed restriction will populate on the right side in green. (It does not show cruise altitude anymore)
FPLN Page


  • Fixed issue where adding via airway would not add all fixes along airway to flight plan
  • Fixed issue where a blank line was not always provided to add a fix
  • Condensed display to only show airway entry and exit as per the real unit
  • Fixed issue where VIA was not displayed on page 2+
  • Fixed issue where attempting to delete the first fix on page 1 would insert CLRIC
  • Fixed issue where unable to delete with a departure active
DEP/ARR Pages


  • Proper formatting and flow of DEP/ARR pages (thanks @tscharlii)
  • Fixed scrolling through procedures and runways (thanks @tscharlii)
  • STAR approaches should now work properly (thanks @tscharlii)
FUEL MGMT Page


  • Total fuel used now initialized to its starting point when the FMC loads
TUNE Page


  • Page now updates and syncs back radio changes made from other instruments or the simulator
PFD/MFD


  • Fixed issue where ILS localizers reporting DME distance as strings would crash the displays
  • Show animated radar bug
  • MFD Checklists have been added
  • Pax Brief Menu has been added (Unfortunately, no sounds for it yet, next release)
  • Added FMS Text option (this essentially displays the PROG page on the MFD)
  • Added functional PASS BRIEF, CHECKLIST, and SYS buttons on the CCP (Cursor Control Panel)
Audio


  • Improved BELT button audio (Currently the chime is non-functional for this. Fix soon)
  • Added SAFETY button chime and announcement and also chime when you turn the SAFETY and BELT buttons off.
  • Increased volume of pilot and co-pilot fan air sounds
Click to expand...

CJ4 v0.4.1 upgrade

v0.4.1 contains mostly bug fixes, but it does contain an awesome sound enhancement - namely Passenger Briefings!
Click to expand...


Notice download is at the bottom of the page.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.4.1
Key Features


  • Added Passenger Briefing Announcements (accessed from MFD Upper Menu and PASS BRIEF BUTTON)
  • Fixed bugs with engine thrust when engines off (#222)
  • Adjusted flight dynamics to minimize (but not eliminate) the AP porpoising effect (#163)
  • Fixed V Speed bug (where v speeds would become stuck at -1 after landing)
  • Updated CAS messages (#242)
  • Sound Updates/Fixes
  • FMS Bug Fixes
Engine Model


  • Thrust when engines off bug squashed (#222)
Flight Model


  • Adjusted elevator trim effectiveness to reduce porpoising and facilitate (careful) FLC usage
LEGS Page


  • Fixed Direct to IAF from LEGS page (#220)
  • Fixed approach waypoint display in LEGS page (#220)
FPLN Page


  • Fixed bug when adding airways (#226) (thanks @tscharlii )
  • Fixed bug where invalid waypoints didn't always cause an error
PROG Page


  • Updated distances to show decimals under 100NM
  • Fixed reversed XTK and CROSSWIND indications on Page 2
PERF Page


  • Added input filters for QNH on takeoff and landing perf pages (user can now enter 29.92, 299 or 2992)
  • Added protection for TAKEOFF and APPROACH REF pages when no runway is selected (error message will appear)
  • Fixed weight calculation issues (#241)
PFD/MFD


  • Fixed FMS Text distances on MFD (#232)
  • Added PASS BRIEF announcements
  • Fixed V Speed bug where some speeds were locked at -1 after a segment (#221)
  • Fixed MFD plane not centered on map (#219)
  • Updated CAS messages for Pitot Heat, Parking Break and Oxy Masks (#242 and #183)
Audio


  • Fixed no chime when playing seatbelt announcement
  • Fixed erroneous chimes when setting battery master to on
  • Fixed sounds for internal/external view swaps/fixed passenger sounds stopping when switching to outside view
  • Added passenger briefing announcements (MFD)
  • Fixed announcements to restrict to only one announcement at a time
  • Improvements to climate control knob sound
Click to expand...


CJ4 vo.5.0 upgrade

Another amazing upgrade for the CJ4.

Download at the bottom of the page. https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.5.0


Key Features


  • Simbrief flight plan import: Added ability to enter your PILOT ID from Simbrief and then load the latest OFP/Flight Plan directly to the FMC (store your PILOT ID in the MOD SETTINGS page and then use the ROUTE MENU to FPLN RECALL)
  • Approach Waypoints: Added ability to skip waypoints on the approach
  • FMS Performance: Greatly improved the performance of the FMS / waypoint loading times
  • Added MFD Memory Functions - MEM buttons now allowing users to save states of the MFD and switch quickly between them (press and hold a MEM button to save the current state to that button)
  • Volumetric External Lights: Incorporated the latest lighting package from Uwajimaya including volumetric external lighting
  • Improvements to PFD and MFD
  • Cabin Lights: Added the ability via the MOD SETTINGS menu to change the cabin light setting
  • FMS: Non functional menu items are now greyed out
LEGS Page


  • Redesigned waypoint loader to dramatically improved flight plan management/FMS performance on LEGS page
  • Added ability to skip approach waypoints or go direct to any approach waypoint / closes #27
FPLN Page


  • Redesigned waypoint loader to dramatically improved flight plan management/FMS performance on FPLN page
  • Added ability to directly download and import the latest OFP from Simbrief - auto load simbrief flight plan directly to FMS!
  • Fixed bug where airways were renamed after entry
DEP/ARR Page


  • Added ability to select VFR runway for landing (when no approach selected or available)
  • Added departure/arrival transitions
  • Fixed display error with approach transitions
PROG Page


  • Fixed several display bugs
PERF Page


  • Added error protection for PERF Pages / closes #253
  • Fixed bug with gross weight calculation
  • Added ability to enter a zero fuel weight number to calculate gross weight instead of pax/cargo entries.
  • Added indication when no runway is selected for TAKEOFF REF and APPROACH REF
  • Added ability to have VFR runway selected to allow PERF pages even when no approach is selected (for airports without approaches)
  • Added vspeed send logic and messages to FMC to replicate real unit
  • Fixed refresh error after entering/updating reserve fuel on FUEL MANAGEMENT page
  • Addressed fuel flow bugs throughout / closes #224
  • Added takeoff time, enroute time, and landing time to flight log page
ARR DATA Page


  • Closer to real ARR DATA page look and feel
PFD/MFD


  • Fix stuck PFD menu when AOA was turned on / closes #251
  • Added elapsed timer functionality to PFD
  • Restructured PFD menu
  • Restructured Lower MFD menu
  • GS is now magenta / closes #249
  • Improved the usability of MFD checklist (saves last opened page and resumes completed section)
  • FMS Text on the MFD will now stay opened after opening MFD checklist or passenger briefing menus
  • Added functionality to CCP MEM buttons, allowing users to save states of the MFD and switch quickly between them
  • Fixed broken fuel reading on SYSTEM OVERLAY menu / closes #246
Audio


  • Fixed audio bugs with announcements
Lighting


  • Incorporated the latest lighting package from Uwajimaya including volumetric external lighting.
  • Added controllable passenger cabin lighting (accessed from FMS -> IDX -> MOD SETTINGS)
  • Fixed some lighting bleed (thanks again Uwajimaya) / closes #171
Click to expand...

CJ4 v0.6.0 upgrade

A big upgrade for the CJ4.
Download at the bottom of the page.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.6.0


A video of these changes.




Key Features


  • Overhauled PFD/MFD for better readability
  • Added bearing pointers to PFD
  • Mach number climbs work
  • Transponder works
  • Simbrief import fixes and error messages with database issues
  • Proper altitude constraints (No VNAV yet) and arrival/approach sequencing.
  • Added approach transitions for arrivals
FMS


  • Added proper input detection for Takeoff Ref Page
  • QNH now automatically pulls from the PFD so there's no need to type it in
  • Takeoff v-speeds and field length won't show if temperature or runway is not inputted
  • Error messages for when the simbrief flight plan waypoint can't be found in sim database
  • Added approach transitions for arrivals
LEGS Page


  • Proper altitude constraints for arrivals and approaches will be shown
  • Adding an approach to an arrival should not put in 2 of the same fixes.
TUNE Page


  • Fixed a bug where swapping COM2 would swap COM1 instead
  • Transponder now works (You must select it from the TCAS mode from STBY to TA/RA)
PFD


  • Better readability of target altitude
  • Changed the target altitude bug to look like in the real plane
  • The altitude select bug won't disappear when within 300ft of current altitude
  • Baro setting is now easier to read
  • Mach number will show correct value and 2 decimal places. (M0.71 vs M0.714)
  • Mach number readout below airspeed tape is now easier to read.
  • Added bearing pointers for FMS/VOR/ADF and accompanying data block
  • Tuning radio from PFD was removed
MFD


  • Overhauled font, sizing, and positioning of upper engine readout displays for better readability and accuracy
  • Fixed pitch trim indicator (was backward) and adjusted default trim position for better takeoff attitudes (Danice737)
  • Fixed ISA temp deviation calculations (Temps should level off at 36,000 at the tropopause)
  • FIxed battery amps displays so it's not -500 anymore (Electrical system still WIP) (Danice737)
  • Added hydraulic pumps tied to N2 so they reach full normal pressure by 20% N2.
Click to expand...

CJ4 v0.7.0 upgrade

The CJ4 moves ahead with more great work.

The download link. https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.7.0


A video of the upgrade.



Important Feature Change

The active flight plan route will no longer be displayed in the ARC or ROSE modes. This is accurate to the actual aircraft. The ARC and ROSE modes are designed to work with the course pointer system. If you would like to see the flight plan route, you must use the PPOS display mode (very similar to ARC, except with the active flight plan instead of pointers) or the PLAN mode.
To activate the new altitude select range indicator (altitude banana), press DSPL MENU on the FMC, then go to page 2. Press LSK3L to activate the indicator. The indicator will only be displayed in the PPOS mode.
Click to expand...



Key Features


  • Added proper VOR navigation modes, including the ability to track VOR1 and VO2
  • Added capability to set CRS on both VOR1 and VOR2
  • MFD MEM mode memory persists between flights
  • Correct course needles on the PFD and MFD for FMS and NAV
  • Ghost localizer needle overlay in FMS mode
  • Metric units support
  • Top-of-descent (TOD) indicator should now display on the moving map and its position properly calculated
  • Ability to use a GPU on the ground
  • Correct ARC, ROSE, and PPOS display modes
  • Altitude select range arc on PPOS Mode
  • Persistent hide yoke feature
FMC


  • SimBrief load should no longer randomly fail on airway loads
  • Improved scratchpad handling to better reflect the actual unit (thanks @panourgue)
  • Able to hide yokes in MOD SETTINGS and stay persistent
FPLN


  • Setting an origin should now properly clear the whole flight plan
  • Setting destination should clear all procedures
  • Page should now show correct "NOT ON GROUND" if attempting to set origin while airborne
  • Inputting an invalid fix should no longer clear the entire temporary flight plan
TAKEOFF PERF


  • Restored ability to set custom QNH (thanks @panourgue)
  • Pages should no longer crash without selected runways
FUEL MGMT


  • Fixed issue where fuel management page would spontaneously continue to reappear (thanks Wombii)
SELECT WPT


  • Overhauled the waypoint disambiguation page to reflect the real unit layout
  • Suggested fixes should now be orderd by distance from plane position
  • You can now go to multiple pages of SELECT WPT, should there be any (thanks Danice737)
MOD SETTINGS


  • A GPU can now be connected to the plane on the mod settings page
  • Cabin lights are now properly tied to the battery bus state. This should also bring the flashlight back
  • Cabin lights state should be properly saved between flights and will no longer default to on
  • You can now clear your input SimBrief pilot ID (thanks @panourgue)
  • You can now select metric or imperial units for the aircraft
TAKEOFF REF


  • You can now go to all takeoff ref pages even without a selected runway
DEP/ARR


  • Pressing the DEP/ARR FMC button should now take you automatically to the appropriate procedure phase as it does in the real unit
  • Page no longer miscalculates the number of total pages
  • Available approach runways from the selected arrival should now match correctly
  • The LSK should no longer select the wrong runway if an arrival is also selected
PFD/MFD


  • ARC, ROSE, and PPOS modes have been overhauled. You should no longer see the route map in ARC and ROSE modes, but only in PPOS and PLAN modes (Selected from FMS DSPL MENU)
  • Properly modeled and styled course needles have been added to the ARC and ROSE modes reflective of the real aircraft
  • The dotted blue ghost localizer needle now shows in ARC and ROSE if you have FMS selected, a localizer tuned, and within range (~30NM from airport)
  • The altitude range arc has been added to PPOS mode and will now show when you will reach your selected target altitude (thanks WT Garmin team)
  • Metric and imperial units switch should be reflected on the PFD/MFD
  • Top-of-descent (TOD) indicator should now display on the moving map and its position properly calculated
  • Heading bug resized
  • Heading bug and line should now appear and disappear properly in the ARC and ROSE modes
  • Changed color of deviation diamonds to green when on an ILS
  • Changed deviation diamonds from filled to outlined diamond for accuracy
  • Magenta track bug hidden when on the ground, resized, and overlayed over heading bug for visibility.
  • When switching to NAV1 or NAV2, you can now select the NAV AP button to enable tracking the tuned VOR or localizer
  • The weather radar sweep indicator should no longer show when WX is not being displayed
  • Bearing pointers should no longer show in PLAN mode
  • Fixed VSpeeds turning cyan when selecting options in the PFD menu
PROG


  • Fixed crash when there was no flight plan
Known Issues


  • The speed constraints on arrivals may not show correctly because of database issues.
  • After using Direct-To, the navigation will not always automatically sequence to the next fix and may enter ROL mode. You can re-activate NAV to navigate to the next fix if you encounter this issue.
  • The aircraft is still using the built-in MSFS autopilot (for now). All the existing limitations of that still apply. It does behave a bit better with the various enhancements applied.
  • Some flight plan distances may still be misreported when the approach is activated. Please log an issue if you encounter this with details.
  • Some instances of the autopilot skipping approach waypoints still occur - this is deep in the sim handling of waypoints and is, for now, out of our hands. We will continue to research this.
Click to expand...

CJ4 v0.7.1 upgrade

A hotfix and upgrades.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.7.1
Key Features


  • Added backlighting to lower CCP panel to complete lighting on the panel
  • Fixed bugs with freezing MFD and FMC in some situations
FMC


  • Fix Metric conversion errors on perf init
  • Fix Metric conversion errors on fuel mgmt
FPLN


  • Fixed error with certain navaid loading when search query returns an empty value (example case NDB HM)
PFD/MFD


  • Repaired map conflict with other WT mods that share the same common mapping code (thanks to Viralwhite for initial diagnosis help)
  • Resolve freezing MFD/PFD error with altitude constraint selection (this option has been disabled as the data is inaccurate)
  • Fixed bug displaying waypoint names in black on black background
  • Adjusted leg colors to show active leg magenta, and others in white
PROG


  • Fixed metric conversion display errors
Known Issues


  • Altitude constraints are not currently selectable on the map due to incorrect data being displayed.
  • The speed constraints on arrivals may not show correctly because of database issues.
  • After using Direct-To, the navigation will not always automatically sequence to the next fix and may enter ROL mode. You can re-activate NAV to navigate to the next fix if you encounter this issue.
  • The aircraft is still using the built-in MSFS autopilot (for now). All the existing limitations of that still apply. It does behave a bit better with the various enhancements applied.
  • Some flight plan distances may still be misreported when the approach is activated. Please log an issue if you encounter this with details.
  • Some instances of the autopilot skipping approach waypoints still occur - this is deep in the sim handling of waypoints and is, for now, out of our hands. We will continue to research this.
Click to expand...


CJ4 v0.7.3 hotfix

This is a hotfix for adjusting the autopilot PIDs to temporarily work around the lateral guidance issues some users are experiencing in MSFS update 1.11.6.0.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.7.3
Changes


  • Changed Autopilot PID values to get rid of lateral navigation problems introduced with MSFS update 1.11.6.0
Known Issues


  • Altitude constraints are not currently selectable on the map due to incorrect data being displayed.
  • The speed constraints on arrivals may not show correctly because of database issues.
  • After using Direct-To, the navigation will not always automatically sequence to the next fix and may enter ROL mode. You can re-activate NAV to navigate to the next fix if you encounter this issue.
  • The aircraft is still using the built-in MSFS autopilot (for now). All the existing limitations of that still apply. It does behave a bit better with the various enhancements applied.
  • Some flight plan distances may still be misreported when the approach is activated. Please log an issue if you encounter this with details.
  • Some instances of the autopilot skipping approach waypoints still occur - this is deep in the sim handling of waypoints and is, for now, out of our hands. We will continue to research this.
Click to expand...

You must log in or register to reply here.
Back
Top
