CJ4 - G1000 Mods

CJ4 v0.8.0 upgrade

A major upgrade release.

This update includes an enormous navigational systems overhaul, making it an excellent aircraft for a full range of IFR flight activities and procedures. We have also added a number of other great features, like a full FADEC and sound overhaul. This release is incredibly large, and is such very much a beta release.
Click to expand...


https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.8.0
Key Features


  • Custom Flight Plan Manager
  • Vertical Navigation (VNAV)
  • FADEC
  • Custom Lateral Navigation
  • RNAV capability with LPV
  • Improved FMA Display
  • Sound overhaul (WIP)
  • PFD/MFD improvements (a lot)
  • Map improvements
  • Many many more...
Custom Flight Plan Manager


  • Independent from MSFS flightplan
  • Much improved procedure data, even when using the stock NavBlue data
  • Modifiable approaches
  • Appropriate discontinuities
  • Direct-to to any fix on the plan at any time
  • Correct vectors, heading-to-altitude, and intercept legs
Vertical Navigation (VNAV)


  • Full support of all CJ4 VNAV modes including VVS, VFLC, and VPATH
  • Continuous vertical path calculation
  • Display of vertical path snowflake
  • Display of required vertical speed donut to meet next restriction
  • Display of TOD on the map
  • Overhauled altitude modes including ALTS and ALTV
  • Ability to add custom altitude restrictions in FMC LEGS page
Lateral Navigation


  • New lateral navigation over the top of existing AP
  • Greatly improved bank response and turn performance
  • Supports correct discontinuity behavior
  • Compatibility with the new Flight Plan Manager
  • Much improved ILS APPR capture success rate
RNAV


  • Ability to fly RNAV procedures at all times
  • Correct sensitivity scaling for the enroute (2NM), terminal (1NM), and approach phases (.3NM)
  • Correct PFD annunciations for navigational sensitivity
  • Full LPV approach support, including correct increasing angular sensitivity as distance to threshold decreases
  • Full AP support of APPR and GP modes for RNAV approaches
FADEC


  • Proper flat rating of engine for consistent performance at varying field elevations and temperatures
  • TO and CLB throttle detents with indication on MFD N1 display
  • FADEC properly targets increasing thrust curve and N1 with altitude in CLB
  • Full CRZ throttle range
FMC


  • Reserve fuel can now be changed
  • Revised the format of the FLPN page to better match the real unit, especially for approaches
  • Approach ref temp of zero can now be entered
Engines


  • Light now off occurs at 12% N2
  • Performance adjustments to fit climb profile using FADEC
PFD/MFD


  • Complete overhaul of the PFD Flight Mode Annunciator to match the correct CJ4 mode symbology
  • IAS hold will now automatically switch to Mach when the values are the same
  • IAS/Mach button switch now captures current mach number
  • Added ability to adjust BARO minimums and added minimums aural callout
  • Added altitude capture aural alert and flashing altitude selection indicator
  • Added FMC waypoint sequence alerting: waypoint ident and distance will flash 5 seconds before sequencing
  • Course needles now smoothly swing to position as per the real display
  • Fixed an issue where the upper panel knob also controlled menues in the MFD
PPOS/PLAN map


  • Added “NO FLIGHT PLAN” to ROSE/ARC modes when no flight plan detected
  • Added “DISCONTINUITY” to ROSE/ARC modes when discontinuity is reached
  • Icons updated for airports, waypoints, and intersections
  • Added correct label font and sizing for map labels
  • Procedures should now be drawn more accurately to how they appear in the procedure charts
  • Temporary flight plans (modifying a route) now displays as a dashed white line
New Sounds (work in progress)


  • Engine exterior and interior run, start, stop
  • Avionics fans
  • Spoiler drag, Gear drag, extend, retract
  • Cockpit wind and rain
  • FMS, AP panel, DCP, CCP, and soft buttons
  • Aurals (Altitude Alert, Minimums, AP disconnect, Caution/Warning, Landing Gear, Pull up, Overspeed, Sink Rate, Don't Sink)
  • Removed TAWS System Test (To be replaced with accurate sound)
Misc


  • New camera presets (pax, lavatory etc.)
Click to expand...


CJ4 v0.8.1 upgrade

An upgrade to address issues with v0.8.0.

This is a point release to address some of the issues seen this week with version 0.8.0. This version remains a beta release.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.8.1

KEY FEATURES


  • Added VFR runway approaches - in DEP/ARR you can now choose a VFR runway for landing and specify a runway extension waypoint to be added to the flight plan as far as 25nm from the runway. This allows you to 'roll your own' LNAV/VNAV approach to any runway at any airport. Great for small/private fields! https://streamable.com/idloxs
  • Fixed issue when resuming VNAV climbs and fixed issue when setting missed approach altitude during an RNAV approach with GP.
Compatibility


  • Removed old unused files that were causing a compatibility issue with WT Garmin units and the FBW A32NX
RNAV


  • Fixed an issue where GP would stop descending and capture an altitude when the altitude preselector was moved (i.e. to the missed approach altitude)
  • Fixed an issue where sometimes the active waypoint would sequence to the airport and take the plane off course on an RNAV approach.
MCP


  • Fixed an issue where the CRS would not accept input sometimes while not in LNV or NAV mode
PFD


  • Numerous fantastic cosmetic accuracy updates (contribution by TheFlieger)
  • FMS mach value now always shows only two digits
  • Updated BARO indications to show when STD has been set; updated BARO knob to always set STD pressure when pressed
MFD


  • Numerous fantastic cosmetic accuracy updates (contribution by TheFlieger)
  • Shows IGN indication on engine ignition during startup
  • Don't show TOD marker on map when in Approach Mode
SAI


  • Fixed the baro setting rounding error
FMC


  • LEGS page will no longer intepret entries of lower than FL500 as speed restrictions
  • LEGS order of AB restrictions should now be correct
  • FPLN now allows proper entry of 3 letter ICAO airport codes
  • FPLN selecting Origin or Destination will put the ICAO into the scratchpad
  • Visual approach (runway extension fix) capabilty added to the DEP/ARR page
  • Pressing LSK next to origin and dest will now copy ICAO to the scratchpad
  • FMC should no longer blackscreen when going to the ARR DATA page
  • FP Sync option will now actually be active when set to enabled
  • Added new option "FPLN RECALL (GAME)" to Route Menu to sync the flight plan from world map to the FMS
Flight Plan Manager


  • Fixed issue where some track-to-radial-intercept legs were being dropped from procedures
  • Changed behavior of FP Sync on flight start
  • When FP Sync is off: ATC/VFR plan remains but FMS plan is empty. Enter the flight plan manually or use the FPLN RECALL options
LNAV


  • Fixed issue where LNAV would get stuck in a swapping full left then right bank oscillation
Sound


  • Wind, Spoiler Drag and external engine sounds should now be played on the right audio bus so it doesn't play during pause & volume can be adjusted.
Click to expand...



CJ4 v0.9.0 upgrade.

Major changes including a revised flight model. See description for particulars.
There are a number of feature demo videos.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.9.0

A WIP operators guide.

https://docs.google.com/document/d/1qzxPMTSQRkvau8QOi7xUqNvjx9rbww_qHlso5AT5OnI/edit


KEY FEATURES


  • Added Cross Pointers flight director
  • Flight director now works with AP off, including lateral guidance
  • Added Takeoff Go-Around (TOGA) mode
  • Holds functionality and autopilot, including proper entry types and exit arming
  • Course intercept, Point/Bearing/Distance fixes, Point/Distance fixes, Lat/Lon fixes
  • Completely overhauled Flight Model (WIP) (Credit: Metzgergva)
  • Com 2 can now be used to transmit and receive.
Flight Plan Manager


  • Fixed errors where negative values would be returned for a leg course
  • When approach is loaded, destination airport is removed and the runway becomes the final waypoint
LNAV


  • Off-course sidewinder wandering behavior should be greatly reduced
  • Support added for flying holds
  • FMS now calculates correct DTK for very long legs along changing great circle bearings
  • FMS will now continue to sequence even if the active nav mode source is a nav radio
  • FMS will no longer sequence past the destination runway fix to the airport fix
VNAV


  • VNAV will now continue to the most recent restriction even during a large amount of turn anticipation
  • FPA for approach legs will now be calculated from the FAF so steeper angles can be automatically supported
Autopilot


  • Adjusted VS to round up in approach to prevent drifting under GP (Current AP workaround)
  • Added inhibit .1nm from runway threshold to prevent aircraft from flying towards center of airport
  • Added TOGA functionality. When pressed on ground, provides 10 degree FD pitch up, runway heading tracking. Hotspot to engage is the L FIRE BOTTLE click hotspot
  • VS mode now properly captures the current vertical speed when engaging
  • AP now goes to Roll/Pitch upon landing
  • Fixed issue where APPR sensitivity could appear even outside of the approach segment
  • VS wheel now properly adjusts target aircraft pitch when in PITCH mode
Comms


  • COM2 transmit and receive is now fully supported in the panel and compatible with vPilot
  • COM switches on audio panel can now enable or disable transmit for that channel
  • COM knobs will now disable receive for that channel when turned down
FMC


  • Holding CLR for 1/2 second or longer will clear the entire scratchpad
DIR


  • Page layout has been overhauled
  • Available fixes should properly reflect remaining legs in plan
  • Nearest airports function should now operate
  • Direct-to should no longer route you back to the origin runway if the selected fix is a non-ICAO leg termination (also applies to LEGS)
LEGS


  • Fixed legs page blacking out with empty flight plan
  • Fixed inability to copy magenta TO fix to scratchpad
  • Added lat/lon user waypoints support
  • Added shorthand lat/lon user waypoint support
  • Added place/bearing/distance user waypoint support
  • Added flight plan offset user waypoint support
  • Added ability to drop fix on blue FROM leg to intercept leg course
  • Fixed incorrectly rounded distance displays
  • Added NEW HOLD and HOLD AT support
  • Added support for hold EXIT ARMED and CANCEL EXIT
  • Added AUTO/INHIBIT FMS fix sequencing selection
PERF


  • Fixed bug where it would go to perf init after vnav setup 3/3
  • Fixed cruise altitude cell in perf init from showing FL + 5 boxes
  • Fixed bug in approach ref not showing headwind/tailwind
FPLN


  • V-Speeds will reset when entering a new origin after landing.
  • Airways should now be enterable connecting to the final departure fix
  • Fuel used is now reset with new origin
FPLN HOLD


  • Added hold page support for all data fields, except for QUAD/RADIAL
  • Added support for automatically detected entry type
  • Added support for EXIT HOLD and CANCEL EXIT
  • Wired hold support into EXEC/CANCEL MOD
HOLD LIST


  • Added HOLD LIST page
  • Adeed support for up to 6 holds in list
PFD/MFD


  • Added Cross Pointers (X-PTR) flight director and setting persistence on restart
  • Setting altimeter to hPA stays persistent on restart
  • Cyan vertical speed arrow is now removed when in GP or VPATH
  • Adjusted map ranges to realistic values (5, 10, 25, 50, 100, 200, 300, 600)
  • Corrected PPOS scaling
  • MFD Wind speed font size same as PFD
  • Fixed outer range display cut off
  • Added (N)orth label to PLAN view
  • Wind indicator hidden on PLAN view
  • Various map draw improvements
  • Added correct icons for different VOR types and NDBs
  • Enabled map symbols are now drawn and updated around the current location
  • INTERS now only shows named and non terminal waypoints
  • Added display of terminal waypoints (to be enabled in FMC)
  • Map will show a maximum of 40 symbols as in the real unit (configurable in Defaults in later version)
Misc


  • AOA indicator only lights up on gear down or greater than flaps 15.
  • Standby attitude indicator (SAI) baro settings are changed to whatever is set in PFD.
Click to expand...

CJ4 v0.9.1 hotfix.

A hotfix for the newest release.

This is a hotfix release for 0.9.0 to fix the most pressing issues that came up after release.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.9.1

Bugfixes


  • Fixed issue where ATC window did not refresh electrical system status properly
  • Fixed issue where map lines would be improperly drawn in certain situations and zoom factors
  • Fixed issue where after flying one hold, LNAV would not fly any additional holds
  • Fixed issue where LNAV would skip to the last hold if holds were on back-to-back legs
  • Fixed speed tape overspeed indicator and warning speeds
  • LNAV should no longer wander back and forth in the case of overlapping or duplicate flight plan fixes
  • Fix for DIRECT TO not reactivating the current dirto from the DTO page
  • Fix for DIRECT TO not working after one successful DTO
Click to expand...

CJ4 v0.10.0 upgrade

A large update to improve navigation.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.10.0
Key Features


  • Missed approaches
  • Mandatory hold legs from navdata
  • Revamped VNAV with VNAV Path Smoothing and Vertical Direct-To
  • FMS/PFD/MFD message system
  • Custom ILS guidance
  • Ability to arm LNV, APPR LOC, and APPR LNV modes
  • Automatic NAV-to-NAV transfers
  • Relative terrain map
  • External lighting changes
Click to expand...
Changes

Autopilot


  • Over-the-top custom AP now flies ILS approaches itself instead of relying on stock ILS AP behavior for much better lateral and vertical accuracy
  • TO and GA no longer override the heading bug
  • TO is now disabled upon activating AP
  • GA mode will now sequence to the missed approach if the active waypoint is the runway fix
  • Pressing NAV with FMS selected as the active nav source will now arm LNV if currently in ROLL, HDG, TO, or GA.
  • Pressing APPR will now only arm APPR LOC or APPR LNV if outside of the capture area
  • Will stay in VNAV until glideslope intercept when engaging approach mode.
FMC


  • Scratchpad error messages now clear after 1 second
  • FMC messages now display at the bottom of the display
  • Added MESSAGES page
  • Added numerous FMC messages including LOC WILL BE TUNED, CHECK LOC TUNING, FPLN DISCONTINUITY, etc
  • CRZ ALT inputs now allow "F" plus flight level. Eg. F200 = FL200.
  • Initialize Position message now shows if position not initialized
  • Fixed inserting airways in the middle of a flight plan on the FPLN page
LEGS


  • Sequencing will automatically enter INHIBIT when reaching the destination runway
  • Changing sequencing from INHIBIT to AUTO when the active leg is the runway will automatically sequence into the missed approach
  • Missed approach segment is now displayed at the end of the plan
  • POINT/BEARING/DISTANCE fixes should now have magnetic variance properly applied
  • Entering positive/negative distance for along-track offset waypoints now has the desired effect
DIR


  • Added ability to perform vertical direct-to
  • Added altitude restrictions to display
  • Fixed issue where page prohibited direct-to an approach fix
TUNE


  • AUTO/MAN indication now shows next to selected nav radio frequency
  • Pressing LSK next to nav radio frequency with nothing in scratchpad now goes to NAV CONTROL
  • Adjusting a frequency with nav radios in AUTO automatically switches back to MAN
  • Frequencies should now be remembered on shutdown and restart
  • Added expanded nav radio input format support
NAV CONTROL


  • Added NAV CONTROL page
  • Added ability to put nav radios in AUTO mode, which will automatically tune nearest VORs every 6 minutes for location backup
  • Added nav radio presets
PFD


  • Added correct nav source swapping behavior
  • Added ability to change preset (standby) nav source via DATA knob
  • Added preselect nav source (ghost needle) info block
  • Added preselect nav source deviation indicators (ghost deviation)
  • Nav source should now automatically switch when APPR is active and preselect nav source is armed (NAV-to-NAV transfer)
  • PPOS is now prohibited when FMS is not selected as the nav source
  • PFD message lines now populate based on plane conditions and pending FMC messages
  • FGS display layout has been completely reworked to support armed lateral modes (TheFlieger)
  • FGS display arrow shape is now more accurate (TheFlieger)
  • FGS display now flashes modes on mode changes
  • FGS display now shows NOPATH as PATH with a yellow line through it.
  • Wind indicator position refined to better match real unit (Slip)
  • Flap speeds have been added to the airspeed tape
  • Fixed the VSpeed display formatting to reflect real unit
  • Fixed airspeed band disappearing at bottom end (TheFlieger)
  • Fixed the speed trend indicator
  • Styling of mach indicator corrected (Slip)
PFD/MFD


  • TERR and WX mode indicators should now better reflect the real world unit
  • Range-to-altitude Select (altitude banana) now reflects preselector altitude even while VNAV is operating
  • TERR map now operates properly as a relative terrain indicator
  • Fixed issue where DME-only stations would not appear on the course or bearing needle information blocks
  • Fixed issue where bottom display lines would shift when digits were dropped (TheFlieger)
  • Moved ranges into inner circle for ARC, PPOS, and PLAN modes (TheFlieger)
  • Removed radial markings for inner circle in PPOS mode (TheFlieger)
  • Fixed issue where displayed DTK would sometimes be negative
  • Adjusted styling of bottom information line for more accuracy
  • Fixed bearing pointer data block formatting
  • Fixed issue where bearing pointers would show in incorrect spot in PPOS mode
  • Fixed issue where bearing pointer data block would show VOR when a LOC was tuned
  • Bearing pointer needle should no longer show when untuned or when a LOC only is tuned
  • Bearing pointer display block format updated & aligned correctly
  • Map display range rings should now coincide with the ranges in FMS
MFD


  • Oil Temp and Pressure display format corrected
  • Fixed issue where FMS Text hour display would roll over to 25 hours
Flight Planning


  • Legs with altitude terminations should now be placed in a more reasonable location
  • Origin runway fix should now be at the start instead of the end of the runway
  • Hold-to-manual-termination (HM) legs are now properly parsed and inserted into the plan
  • Corrected issue where hold course would get incorrect magnetic variance applied (neoenstien)
  • FPLN RECALL (Game) will now also import Custom waypoints from the world map
Aircraft Light


  • Strobe lights flash is now realistic (on for 1/2 second)
  • Added white nav lights to back of light assembly on wingtips (Where it should be)
  • Masked lights so bleed won't go over wings.
  • Added pulse lights
  • Taxi, Landing, and Pulse lights buttons are exclusive meaning only one can be on at a time.
Misc


  • Windshield now always heated like in the real plane
  • Fixed fuel timing calculation and display to avoid bad hour wrap-around (neoenstien)
  • Bleed air source is set to NORM on plane load
  • "Aural warning ok" message removed
  • Gear up/down won't play when you are on the ground and you load in.
  • Spoiler drag has been brought back to a more realistic value.
Click to expand...







CJ4 v0.10.1 Hotfix

A hotfix for the previous update.

This hotfix is for pressing issues we did not catch during our QA.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.10.1

[h=1]Changes[/h]
  • Correct missed lift adjustment in FM leading to incorrect stall speeds
  • PFD should no longer allow any preset but NAV1 when nav-to-nav is armed and the active nav source is FMS
  • PFD should automatically set the preset nav source to NAV1 when nav-to-nav-is armed
  • Corrected stuck CHECK LOC TUNING scenarios where addon navdata is incorrect
  • Change navaid datablock to "LOC" from "ILS"
  • Fix VNAV not leveling off at constraints during a climb
  • Alt alert cancel on ALT knob push
  • VNAV Setup page should no longer display CRZALTCELL
  • Fixed issue where VNAV state would become corrupted when capturing a preselected altitude while in VPATH.
Click to expand...

CJ4 v0.10.2 Hotfix

A second hotfix.

This hotfix is for pressing issues we did not catch during our QA.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.10.2
Changes


  • Fix blacked out VNAV Cruise page and VNAV SETUP now defaults to CLB
  • Fixes for VNAV TOD and PATH intercept issues in some situations including a DIRTO
  • Fixes and improvements to LNAV turn anticipation and tracking
  • Fixed GS/GP display issues on FMA in some circumstances
  • Fix Nearest Airports Direct-To
  • Fix Nav-To-Nav transfer while in Auto Tuning
  • Improvements to out-of-sync AP modes after using TO/GA mode or when enabling FLC during ALTCAP
  • Disable waypoint sequencing while on the ground
  • Remove range banana from PLAN view
  • Ensure that nearest VOR search returns in distance order.
  • Disable COM3 which caused ghost ATIS during flights
Click to expand...


CJ4 v0.10.3 upgrade

Please take note of warning about livery conflicts.

Default Livery Conflicts

The alternate default liveries that now ship with MSFS are not compatible with the CJ4 yet at this time. They currently ship with panel.cfg files that do not include our FADEC module. Please use the standard livery or a known compatible 3rd party or community livery.
Click to expand...

This patch brings some improvements and a hotfix for the flight model since the UK update.
Click to expand...

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.10.3

Changes


  • Improvements to automatic VOR search
  • Fix blacked out FPLN page when arrival was loaded from the world map
  • More realistic GNSS POS INIT procedure
  • Added TTG to the FMS info on the MFD
  • Checklist on the MFD should not react to the PFD knob anymore
  • Workaround for doubled flaps lift since the UK update (by metzgerva)
  • Added a prominent(!) warning to the MFD when a incompatible livery is used
  • Fixed typos on the TUN and DEP/ARR index page (by slip)
  • Adjust colors for the terrain map (by slip)
  • Added Datalink section with ability to request METAR/TAF/ATIS (thanks to Syntax for the code and FBW for allowing usage of their API)
  • Added target and current altitude display in meters
  • Improved PFD menus (Visuals, Minimums, V-Speeds...)
  • Improvements to RA/BARO minimums in the PFD menu
  • Minimums are now persisted
  • Fixed V-Speed deactivation logic on speedtape display
  • Added BARO SET page and functionality to PFD menu
  • Show CRS on data block when no frequency is tuned
  • CRS knob should change the needle whether or not a VOR/LOC is tuned in within range.
Click to expand...

CJ4 v0.11.0 upgrade

Upgrades and a hotfix for recent MSFS update.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.11.0


Welcome to the Working Title CJ4 v0.11.0. In this update we introduce Charts, the VNAV Window on the MFD and enhanced datalink, along with a number of other new features, bug fixes and full Sim Update 3 compatibility.
Click to expand...

Changes

PFD


  • PFD Baro preset function added. (After STD is pressed on Baro knob,, a preset value can be selected and swapped with STD press again once passed transition altitude)
MFD


  • Added support for Navigraph Charts (can be selected with CHARTS button on lower control panel).
  • Added VNAV window to FMS text (can be displayed by selecting VNAV WINDOW in the FMC DSPL MENU).
  • Added Advisory Descent (DES instead of TOD) when no arrival or approach is loaded; this will provide an advisory (uncoupled) "DES" point to start descent to reach 1500' AFE 10nm from airport.
FMC


  • Added TUNE page functionality - ATC Control page, dispatch function, format changes,
  • Added VNAV WINDOW option to DSPL MENU.
  • Datalink: Added ATIS support for IVAO.
  • Datalink: Changed default METAR source to VATSIM.
  • Datalink: Added support for facilities with separate departure and arrival ATIS.
VNAV


  • Fixed bug where in certain circumstances below constraints were not observed in the first segment of the vertical flight plan.
  • Adjusted glideslope capture to be more sensitive and only capture with less than half scale deflection.
  • Adjusted visibility of below constraints on departure to allow them to appear on the PFD and in the VNAV MFD window at a greater distance from present position.
FLIGHT MODEL


  • Flight model adjusted and enhanced based on sim update 3 aerodynamic changes.
MODEL


  • Added support for livery painters that adjust the panel.cfg file; see the REPAINT_README.MD file included in the CJ4 Docs Folder (REPAINT_README.md).
Click to expand...


As an aside, you guys saw that Working Title is now officially partnering with the Flight Simulator team, right? They're now all full-time on FS development.


Here's a FAQ on the new relationship.

CJ4 v0.11.2 upgrade

More good news.

This update brings some exciting new features like "night" charts (darkened) and storable pilot waypoints, in addition to some important bug fixes.
Click to expand...


https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.11.2


Charts Integration

Charts in the CJ4 are powered by Navigraph - special thanks to the team at Navigraph for their support with API integration. In order to use the charts in the CJ4, you need to have a subscription that includes charts - https://navigraph.com/products/subscriptions. If you have a subscription, all you need to do is select the NAVIGRAPH line in MOD SETTINGS in the FMC and that will launch your web browser and ask you to log in to your Navigraph account - from there an access token will be issued. These tokens do time out from time-to-time, so if you're prompted by the aircraft, or if you ever encounter difficulties loading charts, please go back to this option and resync your account. Details on using the Charts capabilities are in the user guide.
Please note that occasionally the Navigraph token can time out; this especially happens if you do not exit the sim via the main menu. If that happens, please use MOD SETTINGS to refresh your Navigraph token and make a change to your flight plan, such as going DIRECT TO your current active waypoint - this will refresh the chart link.
Changes


  • Implemented charts dark/night mode (activated when panel lights are off or at full [daytime mode] and are otherwise night mode)
  • Added ability to store up to 20 pilot waypoints (IDX->DATABASE)
  • Added ability to type pilot waypoint idents in LEGS, DIR and FPLN pages
  • Fixed Standby Attitude Indicator and Emergency Light Switches
  • Add Emergency Light CAS Message
  • Fix co-pilot audio panel
  • Fixes for TOD problems, including showing a TOD when in an approach and missing when in cruise
  • Fixed VNAV FPTA error that sometimes could cause LNAV to stop responding
  • Added CHECK SPEED message that will show when your speed is >20kts than the current restriction (remember speed constraints are not automatically loaded from nav data and must be manually entered)
  • Further enhancement of terrain colors for the TERR map option; adds curve points above and below aircraft based on aircraft AGL altitude.
  • Cleanup of some small FMC bugs, including missing Working... messages for some screens.
  • Improved duplicate detection methods when importing flight plans (fewer duplicates will flag)
  • Removed 'select waypoint' page being triggered during an import if there are no exact duplicates
  • Refined TOD rounding on MFD in VNAV WINDOW
Click to expand...










CJ4 v0.12.0 upgrade

A major upgrade, new web pages, operators, checklist and painter's guides.

http://packages.workingtitle.aero/cj4/2021/04/04/cj4-release-v0.12.0.html


Guides: http://packages.workingtitle.aero/cj4/guides/


Changes

VNAV CLIMB

VNAV Climb should now be working correctly - we know that we’ve warned many people in past versions to turn it off if it isn’t working, but at this point we believe it works as designed. As a refresher, in the CJ4, VNAV in climb is NOT A PATH. It simply provides protection for the pilot to not exceed an AT or AT OR BELOW constraint in the departure procedure. The protection exists ONLY for waypoints that are loaded into the FMC as part of a DEPARTURE PROCEDURE. If you add other waypoints beyond the DP, those constraints will not be respected as climb constraints.
AUTOPILOT/MODES


  • Enabled APPR mode for ILS when tuned in PFD even when an approach is not loaded in the FMC.
  • Added custom vertical autopilot to manage altitude capture and hold modes. (note: the ALT button is now tied to H:WT_CJ4_AP_ALT_PRESSED and the emissive lvar is L:WT_CJ4_ALT_HOLD)
  • Added altitude capture for PTCH mode.
  • Added altitude capture for TO/GA modes.
  • Enabled ability to arm LNAV on the ground and set activation at 400’ AGL.
  • Fixed bug with not being able to turn off the Flight Director when FMA modes are annunciated - the FD button will now disable all modes when being turned off, as long as the AP is not on.
  • Fixed bug that prevented VNAV button press from being read when APPR mode was active - now it is only force disabled when GP/GS have been captured and those are the active vertical modes.
PFD


  • Added PITCH REF value to the FMA when in PTCH mode.
  • PFD Baro preset bug fixed where improper units would sometimes display with the baro preset window open.
  • Fixed bugs with selected altitude < 0 or > 45,000; these values will not display AND the simvar values will not exceed those limits (you can’t get stuck below 0 anymore).
  • Removed inaccurate feature of resetting the FMA modes upon landing - they will now remain in the last selected modes until the FD is turned off.
MFD


  • Improved map/terrain mask (thanks Slip!).
  • Improved ROSE/ARC display to better reflect the real aircraft.
  • Improved min wind vector/speed display.
  • Fixed bug where DES waypoint would appear even after it had been passed sometimes on the map.
  • Improved gps track bug on MFD/PFD and enable during ground ops.
  • Added ability for FMS Text VNAV window to display climb data even when no descent/arrival is picked, and also to show arrival/TOD data after climb constraints have passed.
  • Fixed the Range Banana (altitude intercept arc) on the PFD/MFD to only display the point where the SELECTED altitude will be intercepted, not the VNAV altitude.
FMC


  • Added runway slope calculations to Takeoff and Landing Ref pages - you can now enter a slope and the relevant TOFL/LFL number will adjust accordingly.
  • Added landing factor distance selection on Approach Ref page - you can now select the landing factor.
  • Added ability to enter custom/new pax weight on PERF INIT page using format “/XXX” or “5/XXX” and the pax weight value is persistent.
  • Added ability to enter Gross Weight on PERF INIT page to override ZFW and/or Pax/Cargo inputs.
  • Fixed bug where the final approach fix calculation in LNAV sometimes chose the missed approach waypoint as the FAF.
  • Fixed bug that sometimes caused the departure runway to be undefined (black FMC screen) after flight plan import.
  • Adjusted DIRTO and Vertical Direct page and capabilities to fix bug not allowing a second vertical direct, not allowing a vertical direct to a current direct to waypoint.
  • Added ability to select any vertical waypoint with a constraint for a direct to; when constraints are A/B or A/ the altitude targeted will be the ABOVE value.
  • Fixed bug causing VREF/VAPP display error in FMC in certain circumstances.
  • Removed departure runway altitude from flight plan and LEGS page.
VNAV


  • Fixed bug that would prevent a climb in cases where there is no SID, but a STAR exists and has constraints.
  • Adjusted VNAV FMS Text window to display descent data as soon as the last departure constraint is passed, instead of waiting until the departure procedure has been completely flown.
  • Fixed bug with missing some A/B or A/ constraints in the first descent segment in some rare cases.
  • Changed behavior of path smoothing to cause the first descent segment to always be at the requested VPA in the VNAV DESCENT setup page.
  • Fixed bug with VNAV calculations after a DIR TO.
  • Adjusted behavior after FPLN change is made that adjusts the PATH; if the new PATH causes an out-of-activation range problem, AP mode changes to PTCH.
  • Fixed bug where after PATH arms in an ABOVE PATH intercept situation, PATH won’t disarm even if you deviate from intercept parameters.
  • Extensive debugging and fixing of obscure/non-normal cases.
FLIGHT MODEL


  • Adjusted idle thrust.
  • Adjusted 75% thrust error in thrust table.
MODEL


  • Adjusted behavior of the panel light knob to replicate the function of the knob in the real aircraft - full on is DAY setting, and this is the ONLY setting to get daytime charts.
Click to expand...

CJ4 v0.12.1 upgrade

A small hotfix/upgrade.

https://github.com/Working-Title-MSFS-Mods/fspackages/releases/tag/cj4-v0.12.1


Welcome to the Working Title CJ4 v0.12.1. This version brings a few small bug fixes and updates to our v0.12.0 release.
Changes


  • Fixed bugs with parsing TUN page inputs.
  • Minor cleanup on DSPL MENU FMC page.
  • Fixed bugs with leg altitude (constraint) parsing to address some incorrect constraints in some European approaches.
  • Fix for erroneous sim autopilot altitude capture when using a hardware button tied to all the altitude slots and not just slot 1.
  • Fix for some erroneous situations where VNAV PATH kicks you to PTCH incorrectly.
  • Fix for sequencing missed approach on Go-Around after a new approach is selected.
Click to expand...


The operator's guide has been updated.

https://docs.google.com/document/d/1qzxPMTSQRkvau8QOi7xUqNvjx9rbww_qHlso5AT5OnI/edit

You must log in or register to reply here.
Back
Top
